Titano Up2 15,2kW

Titano Up2 15,2kW

Closed firebox with dark grey steel structure. Equipped with black painted retractable door with on side in glass-right or left- unique piece in ceramic glass. Two versions for the circulation of hot air: N = natural convection.V = forced ventilation.Four outputs for ducting hot air. Complete with post-combustion system.

TITANO UP2

15,2kW/395m³

Useful thermal power/Heated volume

Closed firebox with dark grey steel structure. Equipped with retractable door: double face (front+side) ceramic glass, flat front ceramic glass, dark grey door frame. Two versions for the circulation of hot air:

N: natural convection and
V: forced ventilation.

Four outputs for ducting hot air. Complete with post-combustion system.

Technical Data

Dimensions (WxDxH)	960x600x1600mm
Weight	N:293kg/V:303kg
Heatable	395m³
Fumes outlet	200mm
Air Inlet	300mm²
Ducting Outlets	4x140mm
Hearth material	Cast Iron
Total thermal power	20,0kW
Useful thermal power	15,2kW
Efficiency	78%
Consumption	4,2kg/h
