GARDENIA 5.0 STEEL
9,5kW/272m3
Useful Thermal Power/Heated Volume
New, improved, wood-burning cooker with stone covering.
Characteristics:
- New chromeplated handrail
- Ventilated sides in enamelled steel
- Hearth with refractory sides and cast iron bottom
- Extractable ash drawer
- Enamelled cast-iron feet
- Enamelled cast iron front, frame and doors
- Top cooking plate and rings in polished cast-iron
- Doors and frame in enamelled cast iron
- Adjustable primary and secondary air for a better combustion control
- Post combustion system (low emissions)
- Handles with new design
Technical Characteristics
| Dimensions (WxHxD) | 950x864x704mm |
| Weight | 202kg |
| Door opening (WxH) | 225x210mm |
| Hearth dimensions (WxHxD) | 296x306x460mm |
| Oven dimensions (WxHxD) | 307x418x430mm |
| Heatable | 272m3 |
| Fumes outlet | 150mm |
| Draught | 12Pa |
| Air inlet | 120mm |
| Hearth material | Cast-Iron |
| Total thermal power | 11,0kW |
| Useful thermal power | 9,5kW |
| Efficiency | 86,7% |
| Consumption | 2,48kg/h |
